Model : F-150G
The servo soft capsule machine model F-150G, is a fully automatic machine for producing soft capsules. It is
driven by servo motors and provides a good solution for mass production with a production speed of 6 RPM.
Filling volume adjustment and zero-point setting for each die roll are precisely controlled by servo motors
based on the set values of touch-screen. Its PLC touch-screen monitor provides an effective production
management.

SPECIAL FEATURE
1. Easy to operate using touch-screen control system.
2. Precise filling material volume control by servo.
3. Automatic die roll alignment & injection timing by servo.
4. SAVE function for saving the production set values for each product.
5. Can produce both bovine capsules and vegetable capsules.
